APW12 Power Supply Unit Brand New EMC PSU 12V 15V APW121215 for Antminer S19 S19pro T19

APW12

OUT1

DC Voltage

12V-15V

Rated Current(220V input)

233A

Ripple & Noise

<1%

Liine Regulation

<1%

Load Regulation

<1%

Setup Time

<2S

Short Circuit Protection

>10mS

OUT2

DC Voltage

12.3V

Rated Current(220V input)

15A

Ripple & Noise

<1%

Voltage Accuracy

12.2V-12.4V

Line Regulation

<1%

Load Regulation

<1%

Setup Time

<2S

Short Circuit Protection

>10mS

Input

Voltage Range

200-240V AC

Frequency Range

47-63Hz

Power Factor

>0.99(full load)

Leakage Current

<1.5mA（220V 50Hz）

Protection

Low-voltage Input

80-89V AC

Output Short Circuit

Yes

Overheat Protection

Yes

Over-current Output

291A-350A(varies under different voltage)

Environment

Operating Temperature

-20-45℃

Operating Humidity

20%-90%RH(non-condensing)

Altitude

< 2000m

Structure

Dimensions

254.6*251.6*63mm

Net Weight

3.6kg

Cooling System

force-air cooling

Noise

45dBA

Compatible

S19 S19pro T19
