TL494CDR PWM Control Circuit for Power Supply Applications
Couldn't load pickup availability
Have questions about this product? Our team is here to help — just reach out on WhatsApp.
💬 Contact Us on WhatsAppAbout the Product
Efficiently Control Power Supplies with TL494CDR PWM Control Circuit
The TL494CDR is a highly integrated device that combines all the essential functions required to build pulse width modulation (PWM) control circuits, commonly used in power supply applications. This single-chip solution incorporates two error amplifiers, an adjustable oscillator, a dead time control (DTC) comparator, a pulse steering control flip-flop, a 5V regulator with 5% tolerance, and output control circuitry.
All-in-One Solution for PWM Power Control: TL494CDR PWM Control Circuit
Designed for versatility, the TL494CDR offers both push-pull and single-ended output operations, selectable through the output control feature. Its internal circuitry ensures the inhibition of double pulses at either output, guaranteeing reliable performance. The variable dead time feature provides precise control over a wide range, allowing customization to meet specific application requirements.
TL494CDR Technical Features:
| Feature | Details |
|---|---|
| PWM Control Circuit | Complete power control circuit |
| Output Current Capability | 200mA sink or source (unspecified) |
| Output Control | Selectable single-ended or push-pull operation |
| Double Pulse Inhibition | Internal circuitry inhibits double pulses at outputs |
| Variable Dead Time Control | Provides control over a wide range of dead time |
| Internal Regulator | Stable 5V reference supply with 5% tolerance |
| Circuit Architecture | Allows easy synchronization |
