DC Voltage

12V-16V

Ripple & Noise

<1%

Source adjustment rate

<1%

Load Regulation

<1%

Start-up and rise time

<6S

Power-off retention time

>10mS

OUT2

DC Voltage

12.3V

Rated current (three-phase 380V input)

21A

Ripple & Noise

<1%

Voltage Accuracy

12.2V-12.4V

Source adjustment rate

<1%

Load Regulation

<1%

Start-up and rise time

<5S

Power-off retention time

>10mS

Input

Voltage Range

380-415V AC

Frequency Range

50-60Hz

Power Factor

>0.99 (full load)

Leakage Current

<1.5mA (380V 50Hz)

Protection

Input undervoltage protection value

333V AC

Output Short Circuit

Yes

Over-temperature protection

Yes

Output overcurrent protection value

408A-453A

(protection value varies under different voltage)

Environment

Operating Temperature

-20-45℃

Operating Humidity

20%-90%RH (non-condensing)

Altitude

< 2000m

Structure

Dimensions

290mm*250mm*80mm

Net Weight

6.4Kg

Cooling method

Forced air cooling

Noise

55dB
